Today sharing:

Some code that I thought it worth sharing.

It draws what (I think) are pleasing bar graphs.

Just realized that most people here don't know you can whip out a bar graph to put somewhere without leaving the browser...



— 〈  1  〉—

HOW TO USE



To use you can install LaTeX. Or you can use Overleaf.com, for example, if you don't want to install anything; both will produce a pdf document.

Many people find using LaTeX difficult, but to grok it well, you merely need some better examples.



— 〈  2  〉—

CODE



% IF YOU DO NOT WANT TO INSTALL LaTeX AND USE IT TO COMPILE SUCH CODE YOU CAN MAKE A FEW CHANGES TO THIS CODE AS DESCRIBED BELOW AND USE OVERLEAF.COM TO COMPILE A FILE.PDF
\documentclass[12pt,letterpaper,onecolumn,openright]{article} % OR ELSE INSTEAD SET
% OR ELSE INSTEAD SET \documentclass{standalone}
\usepackage{xcolor,pgfplots,tikz}
% AND THEN ALSO WRITE \pgfplotsset{compat=1.14}
% AND THEN ALSO WRITE \usepackage[english]{babel}\usepackage[utf8]{inputenc}\usepackage[T1]{fontenc}

    \definecolor{b1}{HTML}{4F84BD}
    \definecolor{r1}{HTML}{C0504D}
    \definecolor{g1}{HTML}{8DBB79}
    \definecolor{p1}{HTML}{9F4C7C}

\begin{document}\begin{tikzpicture}
    \begin{axis}[
        width  = 1.2*\textwidth,
        height = 8cm,
        major x tick style = transparent,
        ybar=2*\pgflinewidth,
        bar width=14pt,
        ymajorgrids = true,
        ylabel = {\fontsize{8}{12}\selectfont P\,E\,R 100 S\,E\,T\,S (\,256 O\,B\,J\,E\,C\,T\,S)},
        symbolic x coords={Q\,U\,A\,N\,T\,I\,T\,Y,V\,A\,L\,U\,E\,(\,UNITS X\,),V\,A\,L\,U\,E\,(\,UNITS Y\,)},
        xtick = data,
        scaled y ticks = false,
        enlarge x limits=0.25,
        ymin=0,
        legend cell align=left,
        legend style={
                at={(1,1.05)},
                anchor=south east,
                column sep=1ex
        }
    ]
        \addplot[style={b1,fill=b1,mark=none}]
            coordinates {%
                (Q\,U\,A\,N\,T\,I\,T\,Y,343)
                (V\,A\,L\,U\,E\,(\,UNITS X\,),13.72)
                (V\,A\,L\,U\,E\,(\,UNITS Y\,),17.97)};

        \addplot[style={r1,fill=r1,mark=none}]
             coordinates {%
                (Q\,U\,A\,N\,T\,I\,T\,Y,124)
                (V\,A\,L\,U\,E\,(\,UNITS X\,),27.28)
                (V\,A\,L\,U\,E\,(\,UNITS Y\,),37.73)
                         };

        \addplot[style={g1,fill=g1,mark=none}]
             coordinates {%
                (Q\,U\,A\,N\,T\,I\,T\,Y,28)
                (V\,A\,L\,U\,E\,(\,UNITS X\,),12.65)
                (V\,A\,L\,U\,E\,(\,UNITS Y\,),16.50)
                         };

        \addplot[style={p1,fill=p1,mark=none}]
             coordinates {%
                (Q\,U\,A\,N\,T\,I\,T\,Y,5)
                (V\,A\,L\,U\,E\,(\,UNITS X\,),50)
                (V\,A\,L\,U\,E\,(\,UNITS Y\,),65.5)
                         };

        \legend{%
            \textbf{Shorter}\,. . . . . . . .\hspace{1mm}0.04 UNITS,
            \textbf{Abcd}\,. . . . . . . . .\hspace{2mm}0.22 UNITS,
            \textbf{Efgh}\,. . . . . . . . .\hspace{3mm}0.45 UNITS,
            \textbf{Looonger}\,. . . . . .\hspace{2mm}10.0 UNITS%
               }
\end{axis}\end{tikzpicture}\end{document}



Pretty easy, what do you think?
