Today I want to wish that my final project of drawing and design, for those who do not know who I am and my dedicate. I am a mechanical engineering student at the Central University of Venezuela, my project is about an extreme engine made in INVENTOR AUTODESK. , is a very useful software for students and professionals of mechanical engineering.
Well, it works very well and saves me a lot of time to draw by hand.
The star motor in the internal combustion device is composed of cylinders that are moved radially by a crankshaft, it is called the star by its shape, this is a motor that is usually used in civil and military birds.
I will show you the parts of the engine, and finally the emsable, really it is a real journey that makes a project of this type, which has to investigate the planes very well, so that when you go to make the final assembly everything is perfect and There are no inconsistencies, but it's really worth it.
Piece 1
Piece 2
Piece 3
Piece 4
Piece 5
Piece 6
Piece 7
Piece 8
Piece 9
Assemble
