Laboratory Project: Logistic Sequences
Laboratory Projects
Recall from my earlier videos in which I would go over very interesting math applications in the form of "laboratory projects" which are included in the end of some sections in my Calculus book (Early Transcendentals by James Stewart).
Logistic Sequences
A sequence that arises in ecology (study of organisms and their environment) is defined by the logistic difference equation:
pn+1 = k pn (1 - pn)
where pn measures the size of the population of the nth generation of a single species.
To keep the numbers manageable, pn is a fraction of the maximal size of the population, so 0 ≤ pn ≤ 1.
Notice that the form of this equation is similar to the logistic differential equation from my earlier video.
@mes/differential-equations-population-growth-logistic-equation
Retrieved: 10 June 2019
Archive: http://archive.fo/R6QrJ
The discrete (individually separate and distinct) model - with sequences instead of continuous functions - is preferable for modeling insect populations, where mating and death occur in a periodic fashion.
An ecologist is interested in predicting the size of the population as time goes on, and asks these questions:
- Will it stabilize at a limiting value?
- Will it change in a cyclical fashion?
- Or will it exhibit random behavior?
Write a program to compute the first n terms of this sequence starting with an initial population p0, where 0 < p0 < 1.
Use this program to do the following.
Task 1:
Calculate 20 or 30 terms of the sequence for p0 = 1/2 and for two values of k such that 1 < k < 3.
Graph the sequences.
Do they appear to converge?
Repeat for a different value of p0 between 0 and 1.
Does the limit depend on the choice of p0?
Does it depend on the choice of k?
Task 2:
Calculate terms of the sequence for a value of k between 3 and 3.4 and plot them.
What do you notice about the behavior of the terms?
Task 3:
Experiment with values of k between 3.4 and 3.5.
What happens to the terms?
Task 4:
For values of k between 3.6 and 4, compute and plot at least 100 terms and comment on the behavior of the sequence.
What happens if you change p0 by 0.001?
This type of behavior is called chaotic and is exhibited by insect populations under certain conditions.
Solutions:
Solution to Task 1:
Calculate 20 or 30 terms of the sequence for p0 = 1/2 and for two values of k such that 1 < k < 3.
Graph the sequences.
Do they appear to converge?
Repeat for a different value of p0 between 0 and 1.
Does the limit depend on the choice of p0?
Does it depend on the choice of k?
I have tabulated 20 terms for the sequences with the following values for p0 and k.
MES Note: You can download my Excel sheet in the following link.
https://1drv.ms/x/s!As32ynv0LoaIh8N-0itIkBrT5E2YMw
Retrieved: 11 June 2019
Plotting the sequences all together, the following chart is shown:
For p0 = 1/2 the sequence converges to about 1/3 for k = 1.5 and about 0.60 for k = 2.5.
For p0 = 7/8 the sequence still converges to about 1/3 for k = 1.5 and about 0.60 for k = 2.5.
The limit of the sequence seems to depend on k, but not on p0.
Solution Task 2:
Calculate terms of the sequence for a value of k between 3 and 3.4 and plot them.
What do you notice about the behavior of the terms?
Plotting in the same Excel sheet from above, and selecting p0 = 7/8 and k = 3.2, it seems that the terms of the sequence fluctuate between two values (about 0.5 and 0.8 in this case).
Solution to Task 3:
Experiment with values of k between 3.4 and 3.5.
What happens to the terms?
For p0 = 7/8 and k = 3.42 or 3.45 it appears the terms eventually fluctuate between four values.
Note that for the following chart for k = 3.42 my calculus book states that the pattern persists into these four distinct "branches" even after 1000 terms which in that case the first and third terms in the pattern differ by only 2 x 10-9-9 while the first and fifth terms differ by only 2 x 10-10.
These terms are 0.44980, 0.84638, 0.44466, 0.84452, 0.44904, etc.
This pattern is seen more clearly when k = 3.45.
For p0 = 7/8 and k = 3.48 the sequences fluctuates about the terms 0.395, 0.832, 0.487, 0.869, 0.395, etc.
Solution to Task 4:
For values of k between 3.6 and 4, compute and plot at least 100 terms and comment on the behavior of the sequence.
What happens if you change p0 by 0.001?
This type of behavior is called chaotic and is exhibited by insect populations under certain conditions.
The chart for p0 = 0.5 and k = 3.7 is shown below.
Increasing p0 by 0.001 changes the graph completely.
For p0 = 0.75 and k = 3.9 the chart is once again changed completely by modifying p0 by 0.001.
As k increases the values are spread out vertically with extreme values getting close to 0 and 1.
There seem to be some fleeting patterns in these graphs, but on the whole they are certainly very chaotic.
